Here's a collection of vero (stripboard) and tagboard guitar and bass effect layouts that we have put together covering many classic and popular effects in growing numbers. Many of these have been posted on freestompboxes.org, so check that site out for great discussions on building your own effect pedals. Enjoy the builds and please also visit us on Facebook and Twitter
Sunday, 14 February 2010
TS808HW
One for the brave people out there! :o) Now verified by riffer.
Picture of Simon's build (riffer on FSB)
BOM:
C1 - 22nF
C2 - 1uF
C3 - 47nF
C4 - 51pF
C5 - 220nF
C7 - 47uF
C8 - 1uF
C9 - 220nF
C10 - 100nF
C11 - 10uF
C12 - 100uF
D1 - 1N914
D2 - 1N914
D5 - 1N914
IC1 - JRC4558D
Drive - 500K
Level - 100K
Tone - 20K
R1 - 1K
R2 - 510K
R3 - 10K
R5 - 10K
R6 - 4.7K
R7 - 51K
R8 - 1K
R9 - 10K
R10 - 10K
R11 - 220R
R12 - 510K
R13 - 10K
R14 - 10K
R15 - 100R
R16 - 10K
R17 - 1K
R18 - 1K
R23 - 1K
Q1 - 2SC1815
Q2 - 2SC1815
Picture of Simon's build (riffer on FSB)
BOM:
C1 - 22nF
C2 - 1uF
C3 - 47nF
C4 - 51pF
C5 - 220nF
C7 - 47uF
C8 - 1uF
C9 - 220nF
C10 - 100nF
C11 - 10uF
C12 - 100uF
D1 - 1N914
D2 - 1N914
D5 - 1N914
IC1 - JRC4558D
Drive - 500K
Level - 100K
Tone - 20K
R1 - 1K
R2 - 510K
R3 - 10K
R5 - 10K
R6 - 4.7K
R7 - 51K
R8 - 1K
R9 - 10K
R10 - 10K
R11 - 220R
R12 - 510K
R13 - 10K
R14 - 10K
R15 - 100R
R16 - 10K
R17 - 1K
R18 - 1K
R23 - 1K
Q1 - 2SC1815
Q2 - 2SC1815
Keeley Katana Boost
UPDATE (09-02-2012):
Without the chargepump and so requires an 18V supply. The schematic that the earlier layout was created from has been shown to be incorrect. In the scheme the switchable 10u cap was linked to the source of Q2, this in fact needs to link to the source of Q1. Apologies to anyone who has made this up, but it is a quick fix, just unsolder the cable and re-solder it into it's new home as per the updated layout below:
Here is a simple vero chargepump layout if you need a 9 to 18V converter:
Without the chargepump and so requires an 18V supply. The schematic that the earlier layout was created from has been shown to be incorrect. In the scheme the switchable 10u cap was linked to the source of Q2, this in fact needs to link to the source of Q1. Apologies to anyone who has made this up, but it is a quick fix, just unsolder the cable and re-solder it into it's new home as per the updated layout below:
